EQP-121 OBD11 Code Reader E58-3002

Description
Additional information

Overview

This compact, multi-function tool is one of the easiest and quickest solutions to pinpoint Onboard Diagnostic System (OBD) faults and can be used on local and imported vehicles that support the OBDII vehicle communication system.

Some of the features include:

  • Works with all OBDII/EOBD compliant cars, light-duty trucks, SUV’s, minivans and hybrids sold worldwide.
  • Works on all 1996 and later OBD II compliant vehicles.
  • Reads hard and memory codes
  • Turns off Check Engine Light (MIL)
  • Clears codes and resets monitors
  • View live data stream
  • View freeze frame data
  • I/M monitor readiness test
  • Retrieves vehicle information (VIN)
  • Multilingual menu options
  • Supports CAN and all other OBD-II protocols
  • Built-in OBD-II Fault Code lookup library
  • Displays current trip information
  • Displays 02 sensor test data
  • Displays onboard monitor test results
  • Checks vehicle component work status
  • Storage Pouch
  • Software upgradeable via internet
  • Limited one (1) year warranty
  • Suitable for the entry-level pro and savvy DIY user

Is your vehicle compatible? Download our List of OBDII Compatible Cars in Australia

Specifications

Dimensions
Length: 166mm
Width: 88mm
Height: 30mm
Weight: 0.48 kg

Display: Backlit 128 x 64 pixel display with contrast adjustment
Operating Temperature: 0 to 60°C (32 to 140°F)
Storage Temperature: -20 to 70°C (-4 to 158°F)
External Power: 8 to 18 V provided via vehicle

Kit includes
PLUSQUIP EQP-121 OBDII/EOBD Code Reader
User’s Guide
USB cable
OBDII Cable
Storage Pouch

Instruction

EQP-121 User Manual PDF

Download

List of OBDII Compatible Cars in Australia PDF

OBD11 fault codes

List of OBD11 Fault Codes – Generic Powertrain Fault Codes

Model Comparison

PlusQuip OBDII Scan Tools features Comparison with other PlusQuip Models.
See more on the EQP-119 here
See more on the EQP-120 here

EQP-121 OBDMATE Code Reader and Reset Tool comparison

EQP-121 OBDMATE Code Reader and Reset Tool

Weight 0.48 kg
Dimensions 16.6 x 8.8 x 3 cm
